These dead weight testers are easy to use and have a robust design. They have great long-term stability.
These dead weight testers are generally used for occasional to regular calibration by laboratories but also industries.
- calibration : Our dead weight tester are calibrated under the following conditions of use : Temperature 20°C - Pressure atmos. 1013.25 hPa - Humidity 50% - acceleration 9.80665 m/s²
- fluid : Mineral or synthetic oil depending on model, colorless, compatible with medical or food uses.
- tank : 125cm3
- seat adjustment : Leveling bubble and adjustable feet
- motorization of weights : possible with option
- crankcase : Light alloy aluminium AG3 + high-resistance paint
- capstan : Removable for transport
- piston/cylinder : single or dual depending the model
- weights : Ergonomic shape of the masses, easy loading of the masses on the bell - Marking corresponding with the measuring unit choose (bar, mbar, KPa, PSI etc..) – Gravity : standard (9.80665 m/s² or local gravity at your choice without supplement
- operating temperature : 18 to 28°C - 64 to 82°F
Filter your seach by measurement
Results for : Hydraulic > Hydraulics dead weight testers > High performance dead weight testers BH2
See the details
See the details
See the details
See the details
See the details
See the details
huile
BH2-30B
- measuring : from 0.1 bar to 30 bar / from 2 PSI produits.à 400 PSI
- reference : BH2-30B
- number of pistons : 1
See the details
huile
BH2-60B
- measuring : from 0.2 bar to 60 bar / from 3 PSI produits.à 800 PSI
- reference : BH2-60B
- number of pistons : 1
See the details
huile
BH2-150B
- measuring : from 0.5 bar to 150 bar / from 10 PSI produits.à 2000 PSI
- reference : BH2-150B
- number of pistons : 1
See the details
huile
BH2-300B SP
- measuring : from 1 bar to 300 bar / from 15 PSI produits.à 4000 PSI
- reference : BH2-300B SP
- number of pistons : 1
See the details
huile
BH2-300B DP
- measuring : from 1 bar to 300 bar / from 10 PSI produits.à 4000 PSI
- reference : BH2-300B DP
- number of pistons : 2
See the details
huile
BH2-400B DP
- measuring : from 1 bar to 400 bar / from 10 PSI produits.à 6000 PSI
- reference : BH2-400B DP
- number of pistons : 2
See the details
huile
BH2-400B SP
- measuring : from 1 bar to 400 bar / from 15 PSI produits.à 6000 PSI
- reference : BH2-400B SP
- number of pistons : 1
See the details
huile
BH2-600B SP
- measuring : from 2 bar to 600 bar / from 30 PSI produits.à 8000 PSI
- reference : BH2-600B SP
- number of pistons : 1
See the details
huile
BH2-600B DP
- measuring : from 1 bar to 600 bar / from 10 PSI produits.à 8000 PSI
- reference : BH2-600B DP
- number of pistons : 2
See the details
huile
BH2-700B SP
- measuring : from 2 bar to 700 bar / from 30 PSI produits.à 10000 PSI
- reference : BH2-700B SP
- number of pistons : 1
See the details
huile
BH2-700B DP
- measuring : from 1 bar to 700 bar / from 10 PSI produits.à 10000 PSI
- reference : BH2-700B DP
- number of pistons : 2
See the details
huile
BH2-1200B DP
- measuring : from 1 bar to 1200 bar / from 10 PSI produits.à 16000 PSI
- reference : BH2-1200B DP
- number of pistons : 2
See the details
huile
BH2-1200B SP
- measuring : from 2 bar to 1200 bar / from 30 PSI produits.à 16000 PSI
- reference : BH2-1200B SP
- number of pistons : 1
See the details
huile
BH2-2000B
- measuring : from 40 bar to 2000 bar / from 600 PSI produits.à 30000 PSI
- reference : BH2-2000B
- number of pistons : 1
See the details
huile
BH2-2500B
- measuring : from 40 bar to 2500 bar / from 600 PSI produits.à 36200 PSI
- reference : BH2-2500B
- number of pistons : 1
See the details
huile
BH2-3000B
- measuring : from 40 bar to 3000 bar / from 600 PSI produits.à 44000 PSI
- reference : BH2-3000B
- number of pistons : 1
See the details
huile
BH2-4000B
- measuring : from 40 bar to 4000 bar / from 600 PSI produits.à 60000 PSI
- reference : BH2-4000B
- number of pistons : 1
See the details
huile
BH2-5000B
- measuring : from 40 bar to 5000 bar / from 600 PSI produits.à 72000 PSI
- reference : BH2-5000B
- number of pistons : 1
See the details
huile
BH2-6000B
- measuring : from 200 bar to 6000 bar / from 2000 PSI produits.à 80000 PSI
- reference : BH2-6000B
- number of pistons : 1
See the details
huile
BH2-7000B
- measuring : from 200 bar to 7000 bar / from 2000 PSI produits.à 100000 PSI
- reference : BH2-7000B
- number of pistons : 1
See the details
